Description-
- Superior quality aluminum alloy construction.
- Energy efficient Electrical Steel Sheet and 99.9% Pure Copper Wire.
- “E” grade varnish insulation to protect from electric shock and voltage fluctuation.
- Aerodynamically designed blades for maximum air delivery.
- High quality paint for superior finishing.
- Packed in strong corrugated cartons with protective thermopore.
General Specifications
Type Blades Sweep Warranty BLDC Hybrid 3 1400mm Yes Technical Specifications Inverter
MODE TYPE AC MODE DC MODE Rated Mode 230 VOLT AC 12 VOLT DC Power Input 55 WATT 45 WATT Frequency 50 Hz NA Current in Phase 0.25 A 3.75 A Speed @ Full 1400 rpm 1350 rpm Speed @ Slow 610 rpm 605 rpm Air Delivery 100 m3/min 85 m3/min Power Factor 0.97 NA Service Value 1.80 m3/min/W 1.85 m3/min/W Control of Fan REMOTE CONTROL REMOTE CONTROL Remote Type RF REMOTE RF REMOTE No. of Speeds 07 07 Winding Material Pure Copper Pure Copper Timmer 1H-4H-8H 1H-4H-8H What is in the Box-- Motor
- Blades
- Down Rod
- Shakle
- Canopy
- Screws & Nuts
